Plane connecting rod type groove control structure is stable and flexible, and has obtained the "high-tech product certification".The whole machine is designed in one piece, with many models, convenient installation and debugging, and good accuracy retention.
The structure is stable, heavy and durable. The structural parts are tempered to remove the internal stress, and the imported high-precision gantry pentahedron machining center is used for one-time positioning processing, which has high strength, rigidity and precision.
Three-dimensional software docking, automatic calculation, saving labor and material and high efficiency.
A strong R&D team ensures the quality and high technology of the equipment;
Sophisticated equipment and complete technology ensure the accuracy of the equipment;
Strict on-site management and testing ensure its excellent workmanship;
The perfect after-sales service team ensures the stable operation of the equipment;
| Name | Parameter value | Name | Parameter value |
| Moving column cutting head stroke | ≥6m | Chuck type steel pipe clamping method | Manual or Electric |
| Bracket type steel tube support structure | Manual or hydraulic | Dedicated intersecting wire cutting programming | Quantitative built-in intersecting line expansion and cutting macro library, 3D import |
| Swing angle range of plane link type groove control structure | ±45 | Transmission mechanism | Linear guide, ball screw, rack and pinion combination |
| Cut tube | Round or square tube | Cuttable form | Truncation, opening, intersecting line, can be grooved |
| Number of control axes | 2, 3, 5 axes, standard 5 axes for bevel cutting | Cut pipe diameter | According to customer requirements |
| Cutting method | Plasma or flame | Maximum length of pipe | ≤12m |
| Pipe clamping method | Chuck | Power drive | High precision AC servo + special planetary reducer |
| Control System | Dedicated intersecting wire cutting system; controllable 6 axes, quantitative built-in intersecting wire cutting macro library | ||
Korean steel structure customer site
Samsung customer site in South Korea
Singapore oil pipeline customer site
Israeli engineering and construction customer site
Vietnam steel structure customer site
Georgia Power Customers
Export to Brazilian shipbuilding industry customers
Export to Russian chemical industry customers
